Duclos 70-180mm T3

  • Based on the venerable Leica 70-180mm f/2.8. The all new housing designed by Duclos Lenses was done so with careful consideration for professional cinematographers and the motion picture industry. The body is machined from aircraft grade aluminum alloy, anodized black for a lightweight, durable finish. A precision ground stainless steel Arri PL or Canon EF mount allows the Duclos 70-180mm to be natively mounted to a wide variety of cinema cameras including imminent 35mm full frame and Vista Vision systems. Integrated 32-pitch (0.8 mod) zoom, focus, and iris gears and a threaded 3/8-16 lens support, and an 80mm front diameter allow for seamless operation with industry standard accessories.

  • Technical Specifications for Duclos 70-180mm T3
    Focal Length 70-180mm
    Max Aperture T3.0
    Format Full Frame / Vista Vision
    Image Circle* Ø*
    Lens Mount PL
    Min. Focus 5'3"
    Front Dia. 80mm, or 95mm
    Filter Thread 77mm, or 86mm
    Iris Blades
    Optical Layout
    Body Material Anodized Aluminum
    Data Protocol N/A
    Length 8-8.5"
    Weight 4.2 lbs.
    *NOTE: Image circle requirements can be subjective.
    Please use best judgment when considering coverage specs.
    Image circle specs provided by manufacturers.
  • - 70-180mm T3
    - Front/Rear Caps

  • Warranty Info
    Updated warranty info coming soon.
    2-Year Duclos Service+ Program.
    • For maintenance and repair, Contact Us.
